Features
- Digital Class-D Linkable Mono Block Amplifier
- Dual MOS-FET Pulse Width Modulation Power Supply
- 1 Ohm Stable Topology / 16 Volt Stable
- 24 dB/octave - Variable State Subsonic Filter
- 24 dB/octave - Variable State Low Pass Filter
- 9 dB/octave - Variable State Bass Boost
- Heavy Duty Copper Layer Double Sided Epoxy PCB
- Extremely High Tolerance Electrical Components For Reliability
- Proprietary Custom Tooled Heatsink with Onboard PCB Support For Vibration Resistance
- High End Silver Tiffany RCA Inputs with Metal Potentiometers
- 0 Power and Ground Inputs
- Strapping Technology
- Multi-Layer Bullet Proof Protection Circuit
- Wired Remote Control with Clipping Indicator
- 1 Year Limited Warranty
Specifications
- Rated Power ( 14.4V at 1% THD )
- RMS Power - 2 Ohm Linked : 4400W
- RMS Power - 1 Ohm Mono : 2200W
- RMS Power - 2 Ohm Mono : 1100W
- RMS Power - 4 Ohm Mono : 550W
- Low Pass Filter ( 24dB/Oct. ) : 35Hz - 250Hz
- Subsonic Filter ( 24dB/Oct. ) : 10Hz - 50Hz
- Frequency Response ( +/- 1dB ) : 15Hz - 270Hz
- Bass Boost ( 45Hz ) :0 - 9dB
- Input Sensitivity ( Volt +/- 5% ) : 6.0V - 0.2V
- Signal / Noise Ratio : 95dB
- Dampening Factor ( 1 Ohm ) : 350 +
- Operation Mode : Output Master / Input Slav
- Power Efficiency ( 4 Ohm ) : 85%
- Fuse Rating ( 14.4V ) : 250A
- Fuse Rating ( 14.4V Linked ) : 500A
- Power Input Connection : 0 Gauge
- Operation Voltage : 8.5V - 16.0V
- Speaker Output Connection : 8 Gauge
- Dimensions ( Inches ) : 8.46" W x 2.59" H x 18.89" L
- Dimensions ( Millimeters ) : 215 W x 66 H x 480 L
